Motorized Electric Brass Ball Valve is a precision manufactured brass ball valve with an electric actuator. It can control the flow of fluid or gas in the most efficient way. It is widely used in all kinds of pipeline systems, including heating, water supply, gas and other automatic control.
Product features:
1.Efficient Electric operation: The Motorized Electric Brass Ball Valve is equipped with excellent electric actuators to ensure rapid and accurate valve opening and closing.
2.Durable Brass body: The valve body and seat of this electric ball valve are made of high quality brass for excellent strength, corrosion and wear resistance.
3.Easy installation and maintenance: The simple design makes the ball valve easy to install and its components easy to replace and maintain.
4.Excellent sealing performance: The special material and design of the seat ensures excellent sealing performance and reduces the possibility of leakage.
5.Wide range of controls: The Motorised Ball Valve supports precise flow control from full on to full off.
6.Safe and reliable: It contains a specially designed safety mechanism to ensure the safe operation of the equipment even in the case of power interruption.
|
What does DQF-A*DQQ-A Series do?
DQF-A series motorised ball valves are available for terminal waterway control. Thermostat control the motorised ball valve actuator,and the actuator motor drive the valve ON/OFF to make the medium flow or disconnected, and the fan coil blow at the same time to control the temperature automaticly.
|
◆ Easy installation and cost saving.
◆Closing tightly and having a great differential pressure.
◆ Water flow smoothly and it won't be blocked by slag. KVS value is much larger than common 2- way valve.
◆ Valve opens sofety to guard effectively against water hammer.
◆Main material: forging brass body, seal PTFE / HNBR
◆ Actuator torque: 2N.m
◆ Valve opening torque: <1N.m
◆Nominal pressure: 1.6MPa
◆ Working medium: water
◆Fluid temperature 5~95℃
◆ Stem size: 10x10
Motorized Electric Brass Ball Valve offers an excellent solution for liquid and gas flow control applications, with proven operational performance and durability. Whether in a home or industrial environment, it is an ideal choice.
