The 12v dc water solenoid valve is designed for terminal waterway control. The actuator of the electric ball valve is controlled by a thermostat. The motor in the actuator drives the valve to open or close, thereby achieving the circulation or cutoff of the medium. At the same time, it is used in conjunction with the fan coil system to automatically adjust the airflow and achieve precise temperature control. This system effectively simplifies the automated management of the terminal waterway and provides a more efficient temperature regulation experience.
Product Advantages
Low Voltage Safety
12v dc water solenoid valve is relatively low and highly safe, suitable for home, agriculture and other occasions, especially for equipment or systems that require voltage limitation, reducing the risk of electric shock and equipment damage.
Low Power Consumption
12V solenoid valve has low power consumption, which is very suitable for long-term continuous operation, and can effectively save energy and reduce operating costs.
Fast Response Speed
The solenoid valve can respond quickly to electrical signals and quickly open or close the valve, which is suitable for automated fluid systems that require precise control.
Easy Installation
Due to its compact design, small size and easy installation, it is suitable for systems with limited space and is also convenient for later maintenance.
◆Main body material: forged brass valve body, seal PTFE/HNBR
◆Actuator torque: 3.5Nm
◆Valve opening torque: <1N.m
◆Nominal pressure: 1.6MPa
◆Working medium: water
◆Fluid temperature 5~95℃
FAQ
1.Can 12v dc water solenoid valves be used for high temperature liquids?
Most solenoid valves are safe to operate below 85°C, but some special models can withstand higher temperatures and need to be selected according to the product manual.
2.Are there any requirements for the installation position of the solenoid valve?
Although most solenoid valves can be installed in a horizontal or vertical position, the specific installation direction should be carried out according to the manufacturer's recommendations and product instructions.
3.Can the solenoid coil of the solenoid valve be replaced?
Some 12V solenoid valve designs allow the solenoid coil to be replaced, which can reduce the cost of replacing the entire valve in the event of a failure.
4.Can the solenoid valve be used for pulse power supply?
Yes, 12V water solenoid valves can work normally under pulse power supply, as long as the frequency and duty cycle are suitable for its operating parameters.
5.Can the solenoid valve be used in a vacuum environment?
Some well-designed solenoid valves can work in a vacuum environment, but products specifically designed for this environment should be selected.
