24vdc Solenoid Valve

24vdc Solenoid Valve

24VDC solenoid valve is an automatic control device driven by a 24 volt DC power supply, widely used in flow control of liquids and gases. Its working principle is that when current passes through the electromagnetic coil, a magnetic field is generated, which pushes the movement of the valve core to open or close the valve. When the power is off, the spring resets the valve core to its original state to ensure that the fluid stops flowing.
Send Inquiry
24vdc Solenoid Valve



Because it uses a 24VDC power supply, it is widely used in home automation, industrial control, agricultural irrigation and other fields, especially suitable for occasions that require precise flow control. In addition, this solenoid valve has a fast response speed and can achieve fast opening and closing, which is suitable for applications with high time requirements.



In terms of materials, the 24v DC solenoids valve uses a forged brass valve body, and the sealing material is selected according to the fluid properties, such as fluororubber or EPDM, to ensure its corrosion resistance and durability. Its applicable operating temperature and pressure range is also relatively wide, which can meet the needs of various working conditions.





Product Features


◆Main body material: forged brass valve body, seal PTFE/HNBR

◆Actuator torque: 3.5Nm

◆Valve opening torque: <1N.m

◆Nominal pressure: 1.6MPa

◆Working medium: water

◆Fluid temperature 5~95℃




Installation and maintenance





Installation precautions: Make sure the flow direction is consistent with the arrow on the valve body to avoid improper fluid control due to reverse installation.


Regular maintenance: Check the connection of the solenoid coil, clean the inside of the valve, and replace the seals regularly to ensure the normal operation of the valve.


Troubleshooting: If it does not work or leaks, check the power supply, coil and seal.





FAQ



1.Can the closing time of the solenoid valve be adjusted?
The closing time of the standard solenoid valve is not adjustable, but it can be achieved indirectly through an external controller or flow control device.



2.How to extend the service life of the 24VDC solenoid valve?
Regular maintenance, keep the valve and pipeline clean, avoid overload use and ensure that the working environment meets the design requirements.



3.What impact does the sealing material of the solenoid valve have on its use?
The choice of sealing material directly affects the corrosion resistance, high temperature resistance and wear resistance of the valve, and it needs to be reasonably selected according to the characteristics of the medium.



4.Can the 24vdc solenoid valve work normally under reverse flow?
Most solenoid valves are one-way valves and are not suitable for reverse flow. It is necessary to ensure that the valve is installed correctly to avoid damage caused by reverse flow.



5.What changes will the energy consumption of the solenoid valve undergo under high-frequency operation?
High-frequency operation will lead to increased energy consumption because the solenoid coil consumes more electricity during frequent opening and closing, which may affect the overall energy efficiency.
