Heating Zone Valve

Zoning control: Zone valves can divide large systems into several independent zones, allowing users to precisely control the fluid in each zone according to their needs. For example, in a central heating system, zone valves can be used to control the heating of individual rooms or floors, thereby saving energy.

Automated operation: Many zone valves are equipped with electric or pneumatic actuators, which can be operated through an automated system or remote control to ensure automatic opening and closing of valves under different conditions and optimize energy use.

Various types: Depending on different applications, zone valves can be divided into various types such as ball valves, butterfly valves, gate valves, etc. The selection of the appropriate valve type depends on the system pressure, fluid properties and operating requirements.

Energy saving and environmental protection: By using zone valves, the system can adjust the fluid flow according to actual needs and reduce unnecessary waste, thereby improving energy utilization efficiency, reducing energy consumption and achieving environmental protection.

Product parameters



●Valve body material: forged brass
●Valve stem material: stainless steel 06Cr19Ni10
●Seal material: nitrile rubber (NBR)
●Working medium: cold/hot water
●Fluid temperature: 5~95℃
●Pressure: 1.6MPa
●Ambient temperature: 0~65℃ Maximum relative humidity is non-condensing
●Travel time: 11~15 seconds
●Motor torque: >800gf.cm



1. How to deal with the noise problem of heating zone valve?
Valve noise may be caused by fluid impact, friction between internal valve parts, or improper installation. Ways to reduce noise include using shock-absorbing gaskets, optimizing valve design, adjusting flow rate, and ensuring proper installation.

2. Do regional valves need to be calibrated regularly?
For regional valves with precision control devices, such as electric valves, regular calibration is necessary to ensure the operating accuracy of the valve. Calibration usually involves checking and adjusting the position sensor and actuator of the valve.

3. How to deal with the leakage problem of heating zone valves?
Valve leakage problems may be caused by aging or damage of seals. Solutions include checking and replacing seals, adjusting the operating pressure of the valve, and repairing or replacing damaged parts.

4. What is the operating temperature range of regional valves?
Different types of regional valves have different operating temperature ranges. For example, ordinary PET valves usually operate in the range of -10℃ to 80℃, while high-temperature valves can be designed to withstand temperatures up to 250℃. When selecting a valve, you should choose the appropriate model according to the temperature range of the actual working environment.

5. How can regional valves be integrated with building automation systems?
Zone valves can be integrated with building automation systems (BAS) through standardized communication protocols (such as MODBUS, BACnet) to achieve data acquisition and remote control. The integration process usually requires cooperation with system integrators to ensure the compatibility and functional realization of valves and automation systems.
