Stainless Steel Actuated Ball Valves Advantages
Corrosion Resistance
Stainless steel provides excellent resistance to rust, chemicals, and harsh environmental conditions-ideal for aggressive fluids or outdoor installations.
Automation & Remote Control
With pneumatic or electric actuators, these valves can be controlled remotely, improving efficiency and safety in process automation systems.
Fast and Reliable Operation
Actuated ball valves offer quick opening and closing times, making them suitable for high-cycle or emergency shut-off applications.
Tight Seal & Leak-Proof Design
The ball-and-seat mechanism ensures a bubble-tight seal, minimizing leakage and ensuring process integrity-even under high pressure.
Technical Parameters
| Ordering model | Product model | Valve type | Diameter | Thread size | Kv value | Maximum closing pressure kPa |
Dimensions | |||
| L | H | D | ||||||||
| 15752 | DGQF-B-15*DQQ-B1K-220 | 2 port | 15 | G1/2 | 2.6 | 600 | 118 | 30 | 45.5 | |
| 15753 | DGQF-B-20*DQQ-B1K-220 | 2 port | 20 | G3/4 | 6.5 | 600 | 118 | 30 | 45.5 | |
| 15754 | DGQF-B-25*DQQ-B1K-220 | 2 port | 25 | G1 | 9.5 | 600 | 136 | 37 | 46 | |
| 15755 | DGQF-B-32*DQQ-B1K-220 | 2 port | 32 | G1-1/4 | 15 | 500 | 136 | 37 | 46 | |
| 15756 | DGQF-B-40*DQQ-B1K-220 | 2 port | 40 | G1-1/2 | 24 | 500 | 185 | 48 | 68 | |
| 15757 | DGQF-B-50*DQQ-B1K-220 | 2 port | 50 | G2 | 40 | 400 | 240 | 53 | 87 | |
| 15783 | DGQF-B-15*DQQ-B1M-24AC | 2 port | 15 | G1/2 | 2.6 | 600 | 118 | 30 | 45.5 | |
| 15784 | DGQF-B-20*DQQ-B1M-24AC | 2 port | 20 | G3/4 | 6.5 | 600 | 118 | 30 | 45.5 | |
| 15785 | DGQF-B-15*DQQ-B1M-24AC | 2 port | 25 | G1 | 9.5 | 600 | 136 | 37 | 46 | |
| 15786 | DGQF-B-15*DQQ-B1M-24AC | 2 port | 32 | G1-1/4 | 15 | 500 | 136 | 37 | 46 | |
| 15787 | DGQF-B-15*DQQ-B1M-24AC | 2 port | 40 | G1-1/2 | 24 | 500 | 185 | 48 | 68 | |
| 15788 | DGQF-B-15*DQQ-B1M-24AC | 2 port | 50 | G2 | 40 | 400 | 240 | 53 | 87 | |
| Note: The above table is the commonly used recommended models, please consult for details. | ||||||||||
1. Superior Quality Materials
We use only high-grade 304/316 stainless steel and premium actuators to ensure long-lasting performance, excellent corrosion resistance, and compliance with international industry standards.
2. Expert Engineering & Custom Solutions
With a team of experienced engineers, we offer tailor-made valve solutions to meet the unique requirements of your system, whether it's high pressure, aggressive media, or special actuation needs.
3. Full Range of Actuation Options
We provide electric, pneumatic, and hydraulic actuators with advanced control capabilities, giving you flexible, precise automation and integration with your existing process systems.
4. Reliable Performance & Tight Sealing
Our valves are designed for leak-proof operation, even in demanding environments. Every unit is rigorously tested to ensure dependable sealing, low torque, and long service life.
FAQ
1. What media are your stainless steel ball valves suitable for?
Our stainless steel actuated ball valves can be widely used in a variety of fluid media such as water, steam, air, oil, natural gas, corrosive chemicals, etc., especially suitable for use in food, medicine, chemical and seawater environments with high requirements.
2. Can I choose electric or pneumatic actuators? Which one is more suitable for me?
Yes, we provide three types of actuators: electric, pneumatic and hydraulic. Electric is suitable for occasions that require precise control; pneumatic is suitable for frequent switching and high-speed response conditions; if you are not sure about the selection, we can recommend the most suitable solution for you according to the application scenario.
3. Does the valve support automated control systems? Is there a feedback signal interface?
Yes, our actuators are equipped with standard control interfaces, which are compatible with automated control systems such as PLC and DCS, and can provide switch signal feedback, analog control (such as 4-20mA) and limit switches, etc., which are convenient for remote monitoring and operation.
4. Is the product certified? Can you provide material and pressure test reports?
Our products comply with international standards such as ISO and CE, and some models have passed ATEX explosion-proof certification. We can provide material certification (MTC), pressure test report and third-party inspection report according to customer needs.
