Precise Control: Provides accurate regulation of air or water flow, ensuring optimal temperature and humidity levels.
Energy Efficiency: Helps in reducing energy consumption by maintaining efficient system operation, avoiding overuse of heating or cooling resources.
Durability: Built to withstand high pressure and temperature fluctuations, ensuring long-term reliability and reduced maintenance.
Versatility: Compatible with various HVAC systems, including heating, ventilation, and air conditioning units.
Technical Parameters
| Product Model | DFQ - XFM | DFQ - XF - P - M | DFQ - XFM - 485 | DFQ - XFK |
|---|---|---|---|---|
| Power Supply | 24VAC ± 10% 50/60Hz | 24VAC ± 10% 50/60Hz | 24VAC ± 10% 50/60Hz | 24VAC ± 10% 50/60Hz |
| Power | 0.7 - 2.4W (Stopped)<27W (In motion) | 0.6 - 2.0W (Stopped)<27W (In motion) | 1.1 - 2.4W (Stopped)<27W (In motion) | 0W (Stopped)<26W (In motion) |
| Input Signal | User Selectable 0 (2) - 10V (Input Impedance > 100KΩ) 0 (4) - 20mA (Input Impedance = 500Ω) |
24VAC | ||
| Feedback Signal Output | 0 (2) - 10V (Load Impedance > 500Ω) 0 (4) - 20mA (Load Impedance ≤ 500Ω) Voltage and Current Auto - switch |
24VAC | ||
| Driver Thrust | 5000N | |||
| Stroke | 40mm | |||
| Stroke Time | 240 seconds at 50Hz 200 seconds at 60Hz |
|||
| Terminal | Allows wire diameter 0.3 - 2.5mm² | |||
| Temperature Limitation | Ambient Temperature: - 10 ~ + 55℃ Storage Temperature: - 30 ~ + 60℃ |
|||
| Protection Grade | IP54 | |||
| Humidity | ≤ 95% RH, No Condensation | |||
| Fluid Temperature | ≤ 95℃ | |||
| Weight | 4.5kg | |||
why choose us
Industry Expertise
With years of experience in HVAC solutions, we offer cutting-edge technology and reliable actuator valves tailored to your system's needs.
High-Quality Standards
Our actuator valves are crafted with premium materials and undergo strict quality checks to ensure performance, durability, and safety.
Energy Efficiency
Designed to optimize system efficiency, our actuator valves help reduce energy consumption, lowering operational costs.
Custom Solutions
We provide customizable options to meet specific project requirements, ensuring a perfect fit for your HVAC system's unique needs.
FAQ
1. Can the valve be customized for specific needs?
Yes, we offer customized solutions to meet the specific requirements of different systems, ensuring compatibility and efficiency.
2.How do I know if these valves are compatible with my HVAC system?
Our team offers personalized consultation to ensure compatibility, and we provide detailed product specifications to match your system's needs.
3.Are there any warranties or guarantees for these products?
Yes, we offer warranties on all our products, ensuring that they are free from defects and perform as expected under normal usage conditions.
4.What makes your valves stand out from competitors?
Our valves are built for precision, energy efficiency, and durability. We use top-quality materials and offer customization, ensuring the best fit for your system's performance.
