The 3/4 inch electric ball valve is an advanced fluid control solution that delivers superior performance and reliability in many areas. It is designed to meet today's demands for efficient, precise fluid management. Thanks to its electric operation, it enables finer control and simplifies fluid flow handling.
The core of the device is a finely crafted spherical valve with a diameter of 3/4 inch that provides excellent stability and durability in a wide range of temperature and pressure environments. The design of the valve ensures that it cleverly controls the flow and velocity of fluid in a given pipeline system.This electric ball valve offers two main modes: full open mode and full close mode, designed to make operation easy. With the advanced technology of the built-in electric motor, this operation can be performed quickly and smoothly. Therefore, rib manual operation is not necessary.
In addition to its superior maneuverability, the 3/4 inch electric ball valve is also praised for its outstanding durability and durability. Its construction is well designed and its material is strong and durable to work in the most demanding conditions, including high pressure, high temperature and corrosive fluid environments.Installation and maintenance are also easy. Its compact size and sleek exterior design make it easy to install in any piping system. In addition, it doesn't require regular maintenance or maintenance, which means you can spend less time getting more lasting and consistent performance.
|
What does DQF-D*DQQ-D Series do?
Motorised ball valves are available for terminal waterway control . Thermostat control the motorised ball valve actuator,and the actuator motor drive the valve ON/OFF to make the medium flow or disconnected, and the fan coil blow at the same time to control the temperature automaticly.
|
◆ Easy installation and cost saving.
◆Closing tightly and having a great differential pressure.
◆ Water flow smoothly and it won't be blocked by slag. KVS value is much larger than common 2- way valve.
◆ Valve opens sofety to guard effectively against water hammer.
◆Main material: forging brass body, seal PTFE / HNBR
◆ Actuator torque: 2.5N.m
◆ Valve opening torque: ＜1N.m
◆Nominal pressure: 1.6MPa
◆ Working medium: water
◆Fluid temperature 5~95℃
Finally, the 3/4 inch electric ball valve has passed rigorous quality and performance testing to ensure long-lasting performance and operational reliability.
Whether your needs are precise flow control, improved efficiency, or working with best-in-class tools, this 3/4 "electric ball valve is the ideal choice. The advanced features included, such as electric operation, long service life and minimal maintenance, have kept this product at the forefront of the market.
