The Electric Actuated Ball Valve is a game-changing fluid control product designed for precise and efficient flow control. It combines electric drive technology with a precision valve system, making fluid control simple and precise.
The electric ball valve uses advanced electric drive technology to fine-tune and fully control the fluid flow. The drive is optimized to ensure long-term continuous, efficient and reliable operation in a variety of environments and applications. The use of motor drive mode, no manual operation, greatly reducing the workload of operation.
The valve part is made of high-quality materials, with extremely high strength and corrosion resistance, and can work stably in various harsh environments such as high pressure and high temperature. The unique design of the ball valve can keep the fluid stable during the opening and closing process to prevent water shock caused by excessive flow rate. At the same time, the state of full open and full closed is also very obvious, so that users can clearly know the working state of the valve.
The Electric Actuated Ball Valve is easy to install and operate, and is suitable for use in a variety of complex piping systems. Whether it is installed in a new piping system or replaced in an existing system, it can be done in a very short time. In addition, the maintenance of the product is very superior, basically no routine maintenance.
|
What does DGQF Series do?
DQF-G series motorised ball valves are available for terminal waterway control . Thermostat control the motorised actuator,and the reversing motor drive the valve ON/OFF to make the medium current or disconnected,and make the fan coil blow to control the temperature automaticly.The valve combines dynamic and filter.It can adjusts the water flow,blance the pressre . And t he va ve is equipped with temperature testing interface.
|
◆ Easy installation and cost saving.
◆Closing tightly and having a great differential pressure.
◆Integrated with the filter, filter the medium impurities effectively.
◆Integrated with balance valve, available to balance pressure levels.
◆Integrated with the filter and balance valve, small installation space,low cost, and convenient maintaining.
◆Main material: forging brass body, seal PTFE 、EPDM
◆ Actuator torque: 2N.m
◆ Valve opening torque: ＜1N.m
◆Nominal pressure: 1.6MPa
◆ Working medium: cold, hot water, concentration of <50% ethylene glycol solution
◆Medium temperature 5~95℃
◆ Stem size: 9x9mm
In the design and production process, the product strictly abides by the globally accepted quality and performance standards to ensure that the product can meet the needs of users. After rigorous quality inspection and testing, this product has excellent performance, reliable performance and long working life.
Overall, the Electric Actuated Ball Valve is a fluid control device that is efficient, accurate and offers unmatched ease of operation. Its electric drive characteristics and rugged design enable it to handle a variety of demanding environments while maintaining efficient and consistent performance. This electric ball valve is ideal for all piping systems requiring precise flow control.
