The Motorized Ball Valve 24v is an innovative fluid control device that combines powerful motor drive with a high-precision ball valve design for clean and error-free fluid control.
The electric motor, the heart of this electric valve, uses 24 volts of low-voltage DC power to ensure both the safety of the device and the speed and force of the valve opening and closing. It can easily achieve full on and full off control, precisely adjust the fluid channel to meet a variety of complex control needs.
The valve part, made of high-strength, corrosion-resistant material, can adapt to a variety of harsh environments, including high temperature, high pressure and other conditions. The unique ball valve design ensures that the fluid remains stable during the opening and closing process, avoiding water shock problems caused by excessive flow rates. The status of full on and full off is clear and clear, making the operation more convenient.
The Motorized Ball Valve 24v is easy to install and suitable for all types of piping systems. Whether it is a new architecture pipeline or an old system that needs to be replaced, it can be easily installed in a short time. In addition, its design is simple, almost no additional maintenance, greatly reducing operation and maintenance costs.
|
What does DQF-G Series do?
DDF-G series motorised ball valves are available for terminal waterway control. Thermostat control the motorised ball valve actuator,and the actuator motor drive the valve ON/OFF to make the medium flow or disconnected, and the fan coil blow at the same time to control the temperature automaticly.
|
◆ Easy installation and cost saving.
◆Closing tightly and having a great differential pressure.
◆ Water flow smoothly and it won't be blocked by slag. KVS value is much larger than common 2- way valve.
◆ Valve opens sofety to guard effectively against water hammer.
◆Main material: forging brass body, seal PTFE / HNBR
◆ Actuator torque: 3.5N.m
◆ Valve opening torque: ＜1N.m
◆Nominal pressure: 1.6MPa
◆ Working medium: water
◆Fluid temperature 5~95℃
This product is designed and manufactured in strict compliance with global standards to ensure that its quality and performance are always at the top of the industry. After rigorous quality inspection and performance testing, whether it is durability, accuracy or stability, the 24v Ball Valve performance is outstanding.
In summary, the Motorized Ball Valve 24v combines modern electric technology with precision valve design to handle a variety of demanding application environments while accurately controlling fluid flow, providing unmatched operating convenience. This electric ball valve is ideal for any system that requires precise fluid flow control.
