Stainless Steel Globe Valve

●Valve core: stainless steel 06Cr19Ni10 (two-way), HPb59-1 (three-way)
●Valve stem seal: four-layer V-type and O-type combined nitrile rubber seal, polytetrafluoroethylene sealing sleeve
●Valve stem: stainless steel 06Cr19Ni10
●Valve body, valve cover material: HT250
●Nominal pressure (PN): 1.6MPa
●Working medium: water, fluid temperature 5~95℃
●Valve leakage: ≤0.03%KV
●Flange standard: GB/T 17241.6 PN16

Technical Parameters

Order code	Product Model	Valve type	DN	Connection	Bolt size	Kv value	Stroke	Dimensions					Maximum closing pressure difference [kPa]
Order code	Product Model	Valve type	DN	Connection	Bolt size	Kv value	Stroke	L	d	D	H	H1	Maximum closing pressure difference [kPa]
12664	DDF-S-J-232	2 way	32	Flange	4×M16	21	20	180	∅100	∅135	125	108	600	---------	---------
12665	DDF-S-J-240	2 way	40	Flange	4×M16	28	20	200	∅l10	∅145	128	119	500	---------	---------
12483	DDF-S-J-250	2 way	50	Flange	4×M16	34	20	230	∅125	∅165	128	135	350	---------	---------
12484	DDF-S-J-265	2 way	65	Flange	4×M16	54	20	290	∅145	∅185	140	165	250	---------	---------
12485	DDF-S-J-280	2 way	80	Flange	8×M16	67	20	310	∅160	∅200	147	180	200	---------	---------
12486	DDF-S-J-2100	2 way	100	Flange	8×M16	120	40	350	∅180	∅220	191	200	---------	300	500
12487	DDF-S-J-2125	2 way	125	Flange	8×M16	180	40	400	∅210	∅250	205	230	---------	200	350
12488	DDF-S-J-2150	2 way	150	Flange	8×M20	256	40	480	∅240	∅285	221	270	---------	150	200
12666	DDF-S-J-2200	2 way	200	Flange	12×M20	330	40	600	∅295	∅340	254	329	---------	---------	150
12667	DDF-S-J-332	3 way	32	Flange	4xM16	21	20	180	∅100	∅135	125	90	600	---------	---------
12668	DDF-S-J-340	3 way	40	Flange	4×M16	28	20	200	∅l10	∅145	128	100	500	---------	---------
12489	DDF-S-J-350	3 way	50	Flange	4×M16	34	20	230	∅l25	∅165	128	115	250	---------	---------
12490	DDF-S-J-365	3 way	65	Flange	4×M16	54	20	290	∅145	∅185	140	145	200	---------	---------
12491	DDF-S-J-380	3 way	80	Flange	8×M16	67	20	310	∅160	∅200	147	155	150	---------	---------
12492	DDF-S-J-3100	3 way	100	Flange	8×M16	120	40	350	∅180	∅220	191	175	---------	250	350
12493	DDF-S-J-3125	3 way	125	Flange	8×M16	180	40	400	∅210	∅250	205	200	---------	200	250
12494	DDF-S-J-3150	3 way	150	Flange	8×M20	256	40	480	∅240	∅285	221	240	---------	---------	200
12669	DDF-S-J-3200	3 way	200	Flange	12×M20	330	40	600	∅295	∅340	254	300	---------	---------	150

Selection points

Material: Choose the appropriate material according to the characteristics of the medium in the HVAC system. 304 stainless steel is suitable for general environments, while 316 stainless steel is more suitable for highly corrosive media.

Pressure level: When selecting, make sure that the pressure level of the valve can withstand the maximum pressure in the system.

Valve size: Choose a stop valve of appropriate size according to the diameter of the pipeline to ensure flow control and sealing effect.

FAQ

1.How to install stainless steel globe valves in HVAC systems?

Stainless steel stop valves are generally installed on horizontal pipes to ensure that the flow direction of the medium is consistent with the arrow marked on the valve body, and the valve stem is vertically upward for easy operation and maintenance.

2.How to ensure the sealing performance of stainless steel globe valves?

The sealing surface and valve seat are precisely machined to ensure close contact when closed. At the same time, the corrosion resistance of stainless steel helps to extend the life of the sealing surface and reduce leakage caused by corrosion.

3.How to perform daily maintenance on stainless steel stop valves in HVAC systems?

Regularly check the valve stem, valve disc and sealing surface to ensure that there is no wear or corrosion. Properly lubricate the valve stem to prevent poor operation due to excessive friction.

4.How to extend the service life of stainless steel stop valves?

The service life of ss stop valves can be extended by selecting suitable materials, ensuring correct installation, regular maintenance and use within the design pressure and temperature range.

5.Is the stainless ss globe valve suitable for media containing particles?

It is not recommended to be used for media containing solid particles. The particles may wear the sealing surface and cause the seal to fail. It is recommended to install a filter or use other types of valves before the granular medium.
