Zone Valve Hot Water Advantages
Energy Efficiency: Optimize hot water distribution and reduce energy waste by precisely controlling water flow.
Precise temperature control: Ensure stable temperature in each area of the hot water system to improve comfort.
Convenient maintenance: Designed for quick installation and maintenance, reducing system downtime.
Strong durability: High-quality materials are used to resist corrosion and wear, extending product life.
Automated control: Compatible with automatic control systems to achieve remote operation and intelligent management.
Product Parameters
Valve body material: Forged brass
Valve stem material: Brass
Sealing material: Nitrile Butadiene Rubber (NBR)
Working medium: Cold/hot water
Fluid temperature: 5 - 95℃
Pressure bearing: 1.6MPa
Ambient temperature: 0 - 65℃, with maximum relative humidity without condensation
Stroke time: 11 - 15 seconds
Motor torque: > 800gf.cm
Zone Valve Hot Water Installation Instructions
Pressure reducing valve installation
For high-rise buildings, it is recommended to install a pressure reducing valve on the ground floor branch pipe to ensure the stability and safety of the hot water system.
Motor housing waterproof requirements
The motor housing must prevent water droplets from penetrating, so when the valve is installed, the driver should avoid installing it under the pipe to ensure that the motor housing can be effectively waterproof.
Manual operation setting
The manual operating lever should be moved slowly in the direction of the arrow and pressed into the notch to keep the valve in the normally open state. When the current passes through the electric valve for the first time, the manual lever will automatically return to the "automatic" position.
Driver installation and removal
If the driver is not pre-installed on the valve body, first push the operating lever into the groove, press the black button, install it to the valve body and release it. When removing, repeat the above operation. Note: Make sure that the direction of water flow is consistent with the arrow on the valve body, and the driver must not be used as a force fulcrum.
FAQ
Q: Which areas can be controlled for temperature?
A: The valve is suitable for zone control, and can accurately adjust different areas of hot water supply according to demand to ensure that the temperature of each area meets the requirements.
Q: Does it support remote control?
A: Yes, it supports docking with intelligent control systems, can achieve remote operation and monitoring, and improve user convenience and system intelligence.
Q: How durable is the valve?
A: It uses high-quality materials and precision craftsmanship, has excellent corrosion resistance and durability, and ensures that it is not easy to damage after long-term use.
Q: Is it compatible with existing systems?
A: The valve is designed to be compatible with a variety of heating systems, suitable for existing hot water pipes and temperature control equipment, and can be quickly integrated and play a good role.
