Motorised Butterfly Valve

Motorised Butterfly Valve

The Motorised Butterfly Valve is a high-performance valve designed for precise flow control in various industrial systems. It combines the reliability and ease of operation of a traditional butterfly valve with the automation capabilities of an electric actuator. This valve is ideal for applications requiring efficient, consistent, and precise flow regulation, ensuring smooth operation in a wide range of environments. The Motorised Butterfly Valve is particularly beneficial for applications where frequent adjustments are needed, offering a compact, durable, and energy-efficient solution that enhances system performance.
Send Inquiry
motorised butterfly valve



The Motorised Butterfly Valve is a reliable, efficient, and cost-effective solution for flow control in a variety of industrial applications. Its motorised actuator allows for precise and automated operation, reducing the need for manual adjustments and increasing system efficiency. With its durable construction, energy efficiency, and wide range of applications, it is the ideal choice for industries looking to optimize their operations while ensuring long-term reliability and performance.

Advantages and features

  • Motorised Actuation: The valve is equipped with an electric actuator that allows for automatic operation, making it an ideal choice for systems that require precise, remote-controlled flow regulation. This feature reduces manual intervention and enhances operational efficiency.
    Compact and Lightweight: it features a compact design that saves space while maintaining a robust structure. Its lightweight design allows for easy installation in tight or confined spaces, making it versatile for use in various industries.
    Precise Flow Control: With its smooth, rotating disc, the valve provides excellent flow control, offering precise throttling capabilities. The motorised actuator allows for quick adjustments to flow rates, ensuring accurate control and improved system performance.

motorised butterfly valve
Technical Parameters



Order code Model DN Valve opening angle flow cv value
90° 70°
18240 DFR-01-800 800 68250 34395
18241 DFR-01-900 900 86375 39731
18242 DFR-01-1000 1000 119750 55084
18243 DFR-01-1050 1050 117500 70500
18244 DFR-01-1200 1200 154000 92300
Note: When the valve uses switch control, Cv is selected when it opens at 90°; when the valve uses analog control, Cv is selected when it opens at 70°. The recommended control angle is 25°~70°, and the optimal control angle is 60°~65°.

Applications





  • HVAC Systems: In heating, ventilation, and air conditioning (HVAC) systems, it is used to regulate air and water flow. Its quick actuation and accurate control help optimize the performance of HVAC systems, ensuring energy efficiency and comfort.

  • Pharmaceutical Industry: It is used in pharmaceutical manufacturing to regulate the flow of various liquids, gases, and chemicals. Its hygienic design and precise flow control make it ideal for applications that require strict regulatory compliance.

  • Mining and Metallurgy: In mining and metallurgy, the valve is used to control the flow of slurry, water, and chemicals during extraction and processing. Its durability and ability to operate under extreme conditions make it a reliable choice for these industries.

  • Pulp and Paper Industry: It is used in the pulp and paper industry for controlling water, steam, and chemicals. Its quick actuation and reliability in high-pressure applications help optimize the efficiency of manufacturing processes.

FAQ



Q: How does it improve operational efficiency in fluid control systems?
A: It enhances operational efficiency by enabling precise and automatic control of fluid flow. The motorized actuator allows for remote operation and integration with control systems, minimizing manual intervention.


Q: Is it suitable for high-pressure applications?
A: Yes, it is designed to withstand high-pressure applications. Its robust construction and sealing capabilities ensure reliable performance under demanding conditions. Whether used in oil and gas pipelines, chemical processing, or HVAC systems, it offers consistent flow control without compromising on durability or safety.


Q: How does it reduce maintenance costs in long-term operations?
A: It reduces maintenance costs due to its durable design and low wear and tear. The motorized actuator requires less frequent servicing compared to manual valves or pneumatic alternatives.


Q: How easy is it to integrate into existing systems?
A: It is designed for easy integration with existing systems, including automated control panels and PLC systems. Its compact design and compatibility with various electrical connections make it adaptable to a wide range of industrial applications. The integration process is straightforward, allowing businesses to quickly upgrade their existing systems to improve flow control without the need for significant modifications or downtime.
