High temperature and pressure resistance
Anti - blocking design with large flow
Anti-corrosion, can work in sewage environment for a long time
Body thickened for impact protection
The 2 Way Globe Control Valve is a common control valve that is widely used in HVAC systems, industrial process control and water treatment. It is a valve with flow regulation and pressure regulation functions, which can accurately control the flow and pressure of the medium.The Globe Control Valve uses a spherical spool design for excellent fluid control performance. It controls the flow of the medium by adjusting the opening of the spool, so as to achieve accurate control of the system. The design of the spool makes the valve have less pressure loss and higher flow regulation accuracy, and can meet the flow requirements under different working conditions.
|
What does DDF-S-X do?
DDF-S-X series cast iron valve can adjust the flow of cold/hot water after it matched with DFQ-J series motor actuator. It is widely used in the liquid control system such as the central air-conditioning, heating, water disposal, industry processing and so on.
|
◆ The stem seal: four layer V type O type nitrile rubber seals,PTFE envelope
◆ Stem material:stainless steel 06Cr19Ni10
◆ Valve core:06Cr19Ni10(2-Way), HPb59-1(3-Way)
◆ Body,bonnet material:HT300
◆ Nominal pressure(PN):1.6MPa
◆ Working medium: water, fluid temperature-10-95℃
◆ Valve leakage:less than 0.03%of KVs
◆ Flange standard:GB/T 17241.6-2008 PN16
◆ Hengsen cast iron electric valve series can work in high temperature environment, and has the pressure adjustment function, can automatically balance the pressure, prolong the service life of the product.
◆ Valves are made of high quality materials, designed and modified by professional engineers and can be used in most situations.
◆ The valve can be adjusted to the material and shape according to the customer's requirements to meet the customer's use requirements.
In addition, the Globe Control Valve also has a good pressure regulation function. It can control the pressure of the medium by adjusting the opening of the spool according to the needs of the system. This is very important for systems that need to maintain constant pressure, such as water supply systems, steam systems, etc.The 2 Way Globe Control Valve is also relatively simple to install and maintain. It comes with standard pipe connection sizes and can be seamlessly connected to existing pipe systems. At the same time, it has reliable sealing performance and durability, and can maintain stable performance in long-term use.
In short, the Globe Control Valve is a commonly used control valve, with flow regulation and pressure regulation functions. It realizes accurate control of medium flow and pressure by adjusting the opening of the valve core, and has good fluid control performance and pressure adjustment ability. In areas such as HVAC systems, industrial process Control and water treatment, the 2 Way Globe Control Valve is a reliable choice to meet the control needs of the system.
